Features:
- Regulated Voltage: Supplies stable and regulated voltage to breadboard power rails.
- Selectable Power Output: Allows switching between 5V, OFF, and 3.3V using jumpers.
- Direct Breadboard Connection: Plug in design connects directly to breadboard power rails without extra wiring.
- USB Output: Provides regulated 5V output through a USB port for powering external devices.
- On and Off Switch: Enables easy control of power without disconnecting wires.
- Short Circuit and Overheat Protection: Protects both the circuit and the power supply module.
- Input Diode Protection: Prevents damage from reverse polarity or AC input.
- LED Power Indicator: Indicates when the module is powered on.
Principle of Operation:
The breadboard power supply operates by accepting a higher input voltage and regulating it down to stable output levels using onboard voltage regulators. Once plugged into the breadboard, it distributes regulated power evenly across the power rails. Selectable voltage outputs are configured using jumpers or switches. Safety features such as short circuit protection, overheat protection, and reverse polarity protection ensure reliable operation.
Applications:
- Breadboard circuit prototyping
- Arduino based projects
- Robotics development
- DIY electronics projects
- Educational and training use
Circuit:
Simply plug the module into the breadboard, connect a suitable power source, and the circuit is ready for use.
Technical Details:
- Designed for solderless breadboards
- Provides regulated 5V and 3.3V output rails
- Plug in design for quick installation
- Regulated 5V USB output for external devices
- Independent voltage selection for each power rail
- Onboard power switch
- Up to 1A output at 5V and up to 800mA at 3.3V
- Short circuit and overheat protection
- Reverse polarity protection via input diode
- LED power status indicator
