PLC Like Screwed Wings Shield for Arduino

Features

• Wing style shield design for Arduino boards
• Provides screw terminal access to all Arduino pins
• Three terminal groups for each pin including VCC GND and Signal
• Supports digital pins D0 to D13
• Supports analog pins A0 to A5
• Additional power and ground screw terminals
• Wire jumper for power supply distribution between wings
• Open stacking headers allow additional shields to be used
• Improves safety and reliability of external connections

Pinout Overview

• Digital pins D0 to D13 available on screw terminals
• Analog pins A0 to A5 available on screw terminals
• Three terminal groups per pin VCC GND Signal
• Additional VCC and GND terminals for power distribution
• Power jumper for supplying 5V or Vin to left wing

Applications

• Arduino prototyping projects
• Sensor and actuator wiring
• Educational electronics labs
• Industrial style control projects
• Rapid testing without soldering

Arduino Test Code

int testPin = 13;

void setup() {
  pinMode(testPin, OUTPUT);
}

void loop() {
  digitalWrite(testPin, HIGH);
  delay(500);
  digitalWrite(testPin, LOW);
  delay(500);
}

Technical Details

• Binding post type 3.5 millimeter screw terminals
• Compatible with Arduino V3 form factor
• Supports stacking of additional shields
• Power distribution via jumper 5V or Vin
• Designed for safe and organized wiring
