Raspberry Pi 3 Model A+ Development Board

Raspberry Pi 3 Model A+ Development Board

The Raspberry Pi 3 Model A Plus delivers the same processing performance as the Raspberry Pi 3 Model B Plus but in a smaller and lighter form factor. It achieves this compact size by removing several components and reducing the onboard memory while keeping the powerful processor and wireless capabilities. This board features a quad core ARM Cortex A53 processor running at 1.4 gigahertz. It includes dual band wireless networking and Bluetooth support, making it suitable for compact embedded systems and portable projects. Thanks to the ARMv8 architecture, it can run most ARM based operating systems efficiently.

Package Includes

  • 1 Raspberry Pi 3 Model A Plus board

230.00 AED 230.00 AED Tax Included
230.00 AED Tax Included

Not Available For Sale

This combination does not exist.

Raspberry Pi 3 Board
Contact Us

Terms and Conditions
30-day money-back guarantee
Shipping: 2-3 Business Days

Share



Specifications

  • CPU quad core ARM Cortex A53 at 1.4 gigahertz
  • GPU Broadcom VideoCore IV at 250 megahertz
  • RAM 512 megabyte shared with GPU
  • Storage Micro SD card
  • USB ports one USB two port
  • Wireless networking dual band WiFi 2.4 and 5 gigahertz
  • Bluetooth version 4.2 low energy
  • Camera interface MIPI CSI connector
  • Display outputs HDMI and MIPI DSI
  • Audio output through HDMI and 3.5 mm jack
  • GPIO pins 17 general purpose pins with support for UART I2C SPI and I2S
  • Power input 5 volt through Micro USB or GPIO header
  • Board size 65 mm by 56.5 mm by 17 mm
  • Weight 23 grams

Pinout

The Raspberry Pi 3 Model A Plus uses a 40 pin GPIO header compatible with standard Raspberry Pi pin assignments. The header provides power pins ground pins and multifunction GPIO pins supporting digital input output and communication interfaces.

Getting Started

To begin using the Raspberry Pi 3 Model A Plus you will need a stable 5 volt power supply rated at 2500 milliampere. A Micro SD card with a compatible operating system is also required.

Prepare the Micro SD card using an SD card formatter and flash the operating system using a suitable imaging tool. Once the card is ready insert it into the board connect the power supply and attach the required peripherals such as a display keyboard and mouse.

Operating System

The recommended operating system is Raspberry Pi OS. Other ARM-compatible Linux-based operating systems are also supported due to the ARMv8 instruction set.

Applications

  • Compact embedded systems
  • Wireless IoT devices
  • Portable computing projects
  • Education and learning platforms
  • Media and control applications
