Accelerometer Gyro MPU6500 6DOF Module 3.3V-5V

Accelerometer Gyro MPU6500 6DOF Module 3.3V-5V

The MPU 6500 is a six-axis built-in tracking device that combines a three-axis gyroscope and a three-axis accelerometer in a single compact chip. It is known for high performance, low power consumption, and small size. The device is widely used in drones, robotics, smartphones, gaming device,s and wearable technology. The MPU 6500 includes a built in Digital Motion Processor,r which helps reduce the processing load on the main controller. It supports both I2C and SPI communication, which makes it suitable for real-time motion sensing applications.

Package Includes

  • 1 x MPU 6500 module
  • 1 x pin header

45.00 AED 45.00 AED (Tax included)

Add to cart
Terms and Conditions
30-day money-back guarantee
Shipping: 2-3 Business Days

Features

  • Six-axis motion tracking with three axis gyroscope and three axis accelerometer
  • Low power consumption suitable for battery-powered devices
  • Digital Motion Processor for on-chip sensor processing
  • Configurable accelerometer and gyroscope measurement ranges
  • High accuracy and stable performance
  • Compact size for space-limited designs
  • Supports I2C and SPI communication interfaces
  • On-chip temperature sensor

Specifications

  • Gyroscope range plus or minus 250, 500, 1000, and 2000 degrees per second
  • Accelerometer range plusor  minus 2g, 4g, 8g, and 16g
  • Communication interfaces I2C up to 400 kilohertz and SPI up to 20 megahertz
  • Supply voltage range 2.4 volts to 3.6 volts
  • Typical current consumption accelerometer is 500 microamperes
  • Typical current consumption gyroscopeis  3.6 milliampere
  • Sleep mode current consumption: 8 microampere
  • Operating temperature: minus 40 to plus 85 degrees Celsius
  • Package dimensions: 3 by 3 by 0.9 millimeter LGA package

Pinout

MPU 6500 pinoutJDXFENG MPU6500 6-Axis Gyroscope Accelerometer Sensor Module IIC I2C SPI GY-6500 6-Axis Gyroscope Sensor 6DOF Replace MPU6050 With Pins for : Amazon.co.uk: Business, Industry & Science

  • Pin 1 VCC Power supply from 2.4 volt to 3.6 volt
  • Pin 2 GND Ground
  • Pin 3 SDA I2C data line
  • Pin 4 EDA External data line for SPI
  • Pin 5 ECL External clock line for SPI
  • Pin 6 AD0 I2C address select or SPI chip select
  • Pin 7 INT Interrupt output for motion detection or data ready
  • Pin 8 NCS SPI chip select alternative pin
  • Pin 9 FSYNC Frame synchronization input
