Adapter Plate PCB For ESP8266 SMD Module

Adapter Plate PCB For ESP8266 SMD Module

This ESP8266 Adapter Plate is a dedicated PCB designed to simplify the use of ESP-07, ESP-08, and ESP-12E/12F SMD WiFi modules. These modules typically have a tight pin pitch, making them hard to use on standard breadboards or prototyping platforms. This adapter resolves that by allowing easy soldering and connection of ESP8266 modules, similar to Wemos or NodeMCU boards.

Package Includes:

  • 1 x ESP8266 Adapter Plate for ESP-07/08/12E/12F Modules

10.50 AED 10.50 AED Tax Included
10.50 AED Tax Included

Not Available For Sale

This combination does not exist.

SMD PCB Breakout
Contact Us

Terms and Conditions
30-day money-back guarantee
Shipping: 2-3 Business Days

Share



Features:

  • Compatible with ESP-07, ESP-08, ESP-12E, and ESP-12F SMD WiFi Modules
  • Clearly labeled pinouts on the top layer for ease of use
  • Reserved land-pattern for optional 3.3V voltage regulator
  • Includes 10K pull-up resistor pre-soldered on PCB
  • Option to desolder jumper resistor (R1) to enable onboard regulator (VCC input becomes 4.5V–9V)
  • Perfect for breadboarding and prototyping with compact ESP modules

Applications:

  • IoT Prototyping
  • WiFi Projects
  • Smart Home Devices
  • Embedded Wireless Applications

How to Use:

  1. Tin the Pads: Tin the pads on the adapter plate with solder.
  2. Solder the ESP Module: Place and solder the ESP-12F or other compatible module onto the adapter.
  3. Header Placement: Insert female headers into a breadboard, align the adapter, and solder the headers in place.
  4. Powering: If using an onboard 3.3V regulator, desolder the 0Ω R1 jumper and power the VCC with 4.5V–9V.
