Standard Raspberry Pi 40PIN GPIO extension header, compatible with Raspberry Pi series boards
I2C bus communication for real-time monitoring of battery voltage, current, power, and remaining capacity
Multi-battery protection circuits: overcharge/discharge protection, over current protection, short circuit protection, reverse protection, and equalizing charge
Onboard 5V regulator, up to 2.5A continuous output current
5V USB output for powering additional boards
Batteries warning indicators for easy connection verification
Specifications:
Output voltage: 5V
Charger: 8.4V 2A
Control bus: I2C
Battery supported: 18650 Li battery (NOT included)
Dimensions: 56mm × 85mm
Mounting hole: 3.0mm
Features:
Standard Raspberry Pi 40PIN GPIO extension header, compatible with Raspberry Pi series boards
I2C bus communication for real-time monitoring of battery voltage, current, power, and remaining capacity
Multi-battery protection circuits: overcharge/discharge protection, over current protection, short circuit protection, reverse protection, and equalizing charge
Onboard 5V regulator, up to 2.5A continuous output current
5V USB output for powering additional boards
Batteries warning indicators for easy connection verification
Specifications:
Output voltage: 5V
Charger: 8.4V 2A
Control bus: I2C
Battery supported: 18650 Li battery (NOT included)
