DC-DC Very Small Step-UP Boost Voltage 0.8 - 3.3v To DC 3.3v Converter Module (Per Piece)

DC-DC Very Small Step-UP Boost Voltage 0.8 - 3.3v To DC 3.3v Converter Module (Per Piece)

This 3.3V Boost Converter module is designed to step up low input voltages (as low as 0.8V) to a stable 3.3V output, making it ideal for battery-powered devices and low-voltage systems. It utilizes inductor-based energy storage and release to achieve this efficient voltage boost.

Package Includes:

  • 1 x Boost Power Module

15.75 AED 15.75 AED Tax Included
15.75 AED Tax Included

Not Available For Sale

This combination does not exist.

Boost Converter
Contact Us

Terms and Conditions
30-day money-back guarantee
Shipping: 2-3 Business Days

Share



Features:

  • Boosts input voltage as low as 0.8V to a stable 3.3V output
  • Maximum output current: 500mA
  • Typical conversion efficiency: 85%
  • Operating frequency: 150KHz
  • Compact size: 11mm x 10.5mm x 7.5mm (L x W x H)
  • Pin spacing: 2.54mm
  • Lightweight: approximately 1g

Voltage & Current Performance:

Input Voltage Output Voltage Output Current Range
0.8V 3.3V 10mA
1 – 1.5V 3.3V 50 – 110mA
1.5 – 2V 3.3V 110 – 160mA
2 – 3V 3.3V 160 – 400mA
>3V 5V 400 – 500mA

Note:

  1. Do not exceed the nominal input voltage; doing so may damage the module.
  2. The input power must be greater than the output power for proper voltage boost.
  3. Do not exceed the nominal output load; otherwise, output voltage may drop.
