Supercapacitor 400F 2.7V 35x68mm

Supercapacitor 400F 2.7V 35x68mm

The new series of cylindrical electrochemical double-layer capacitors (Super Capacitors) provide excellent pulse power performance due to their combination of very high capacitance and very low equivalent series resistance (ESR). They can be used alone or together with primary or secondary batteries to extend backup time, increase battery life, and deliver instantaneous power pulses when needed. These capacitors are ideal for Hold Up, Energy Harvesting, and Pulse Power applications.

Package Includes:

1 x Supercapacitor 400F 2.7V 35x68mm

89.25 AED 89.25 AED (Tax included)

Add to cart
Terms and Conditions
30-day money-back guarantee
Shipping: 2-3 Business Days



Features

  • Size: 35 x 68 mm
  • Capacitance: 400F
  • Rated Voltage: 2.7V
  • High pulse power capability
  • Low ESR
  • Low leakage current

Soldering Recommendations

When soldering Super Capacitors to a PCB, care must be taken to protect the body of the capacitor from heat. Excessive temperature or prolonged exposure can negatively affect performance and shorten the capacitor's life.

  • Do not immerse the Super Capacitor in solder; only the leads should contact the solder.
  • Ensure the body of the Super Capacitor does not touch molten solder, the PCB, or other components during soldering.
  • Excessive heat or repeated temperature cycling may cause the safety vent to burst, or the case to shrink or crack, potentially damaging the PCB or other components.

Hand Soldering

  • Keep the soldering iron tip away from the capacitor body; it should never touch the body directly.
  • Recommended soldering iron temperature is below 350°C.
  • Limit contact time to less than 4 seconds to avoid transferring heat to the capacitor body.
  • Improper soldering may alter the electrical properties of the Super Capacitor or cause permanent damage.
