Supercapacitor 100F 2.7V 22x45mm

Supercapacitor 100F 2.7V 22x45mm

The new series of cylindrical electrochemical double-layer capacitors (Super Capacitors) deliver excellent pulse power performance due to their very high capacitance and very low equivalent series resistance (ESR). They can be used alone or in combination with primary or secondary batteries to provide extended backup time, longer battery life, and instantaneous power pulses. These capacitors are ideal for Hold Up, Energy Harvesting, and Pulse Power applications.

Package Includes

  • 1 x Supercapacitor 100F 2.7V 22x45mm
61.95 AED 61.95 AED (Tax included)

Add to cart
Terms and Conditions
30-day money-back guarantee
Shipping: 2-3 Business Days



Features

  • Size: 22 x 45 mm
  • Capacitance: 100F
  • Rated Voltage: 2.7V
  • High pulse power capability
  • Low ESR
  • Low leakage current

Soldering Recommendations

When soldering Super Capacitors to a PCB, care must be taken to protect the body from heat. Excessive temperature or prolonged exposure can negatively affect performance and reduce the capacitor's lifespan.

  • Do not immerse the Super Capacitor in solder; only the leads should contact the solder.
  • Ensure the capacitor body does not touch molten solder, the PCB, or other components during soldering.
  • Excessive temperatures or repeated temperature cycling may cause the safety vent to burst, or the case to shrink or crack, potentially damaging the PCB or other components.

Hand Soldering

  • Keep the soldering iron tip away from the capacitor body; it should never touch the body directly.
  • Recommended soldering iron temperature is below 350°C.
  • Limit contact time to less than 4 seconds to avoid heat transfer to the capacitor body.
  • Improper soldering may alter the electrical properties of the Super Capacitor or cause permanent damage.
