Transformer AC220V 50Hz to AC9V 10W EI Type Iron Core

Transformer AC220V 50Hz to AC9V 10W EI Type Iron Core

This is an EI iron-core transformer, a device that transfers electric energy from a 220V 50Hz AC circuit to an inductor to step down the voltage. The output provides 9V AC, which can be rectified using a full bridge rectifier to obtain a stable DC voltage.

Package Includes:

  • 1 x AC220V 50Hz to AC 9V 10W EI Type Iron Core Transformer

9.45 AED 9.45 AED Tax Included
9.45 AED Tax Included

Not Available For Sale

This combination does not exist.

Contact Us

Terms and Conditions
30-day money-back guarantee
Shipping: 2-3 Business Days

Share



Specifications:

  • Product brand: Caixin
  • Input voltage: AC 220V 50Hz
  • Output voltage: AC 9V
  • Rated power: 10W
  • Appearance size: 50 x 45 x 44 mm
  • Structure form: single-phase transformer
  • Product model: EI48*24
  • Input line length: 170 mm (red-red)
  • Output line length: 170 mm (blue-blue)
  • Product weight: ~0.36 kg
  • Mounting hole spacing: 61 mm
  • Frequency characteristics: low frequency
  • Core shape: EI type iron core
  • Cooling method: natural cooling
  • Cooling way: inflatable
  • Linear: two red lines are input, two blue lines are output
