Features
- Long-distance detection: Up to 2 meters range.
- Wide material detection: Detects multiple materials, not limited to metal.
- Photoelectric induction: Reliable detection technology.
- Easy installation: Supports flush, bracket, or through-hole mounting.
- Durable build: Sturdy design for harsh environments.
- Error correction: Compensates for environmental measurement errors.
Specifications
- Voltage: 5VDC
- Current: 5mA
- Measurement Range: 0.1 – 2m
- Output: NPN, normally open (can drive low-level signal relay module)
- Probe Size: 20 × 10 × 8mm
- Wire Length: 1m
- Weight: 10g
Applications
- Automatic counting equipment: Counting products on conveyor belts.
- Security alarm systems: Detecting presence for triggering alarms.
- Traffic detection: Detecting vehicles, bicycles, or pedestrians at intersections.
Pin Connections
| Wire Color | Connection |
|---|---|
| Red | VCC |
| Black | GND |
| Green | OUT |
