Adapter USB Male to Female Type-C 4P 2.54mm USB Module Converter

Features

• Product number: XY-USB4.
• Multi-interface USB converter board.
• Includes USB Type-A male connector.
• Includes USB Type-A female connector.
• Includes Micro USB female connector.
• Includes USB Type-C female connector.
• Includes a 4-pin 2.54 mm interface.
• 4-pin interface provides VCC, D-, D+, and GND.
• Can be used for USB power and voltage interface connections.
• Can be used for USB data interface connections.
• Compact design suitable for development and testing.
• Multiple interfaces allow different connection combinations.
• Can be cascaded for extended USB connections according to the application.

Principle of Operation

The XY-USB4 provides direct electrical connections between its different USB interfaces. Depending on how the board is connected, USB power and data signals can be accessed through the available connectors.

The board does not require a software library for basic interface conversion. USB power lines are provided through VCC and GND, while USB data communication uses the D+ and D- lines.

Pinout:

Applications

• USB interface testing and development.
• Microcontroller and development board projects.
• Embedded electronics prototyping.
• USB power distribution and connection.
• USB data interface testing.
• Laboratory and electronics workbench applications.
• DIY electronics projects.
• Connecting USB Type-A, Micro USB, USB Type-C, and 2.54 mm header interfaces.
• Projects requiring a compact multi-interface USB connection board.

Technical Specifications
