Cable Connector SM 2.5mm Male & Female Plug With Wire Cable 5-Pin 15cm

Cable Connector SM 2.5mm Male & Female Plug With Wire Cable 5-Pin 15cm

This 5-pin SM male and female connector plug set is ideal for quick-disconnect electrical connections in LED lighting systems, DIY electronics, and various DC applications. Each connector is pre-wired with 150mm cables, offering convenience for direct soldering.

Note: Wire colors may vary depending on the batch.

Package Includes:

  • 1 × SM 5-Pin Male Housing Connector with Wire
  • 1 × SM 5-Pin Female Housing Connector with Wire

7.35 AED 7.35 AED Tax Included
7.35 AED Tax Included

Not Available For Sale

This combination does not exist.

SM 2.5mm
Contact Us

Terms and Conditions
30-day money-back guarantee
Shipping: 2-3 Business Days

Share



Specifications:

  • Connector Type: SM 5-Pin Male & Female
  • Pitch: 2.5mm
  • Wire Type: 26 AWG
  • Wire Length: Approx. 150mm (15cm)
  • Wire End: Solder bare wire
  • Voltage Rating: 250V DC/AC
  • Current Rating: 3.0A DC/AC
  • Operating Temperature: -25°C to +85°C
  • Withstand Voltage: 500 VAC/min (effective value)
  • Insulation Resistance: ≥1500MΩ
  • Contact Resistance: ≤0.02Ω
