Battery Lithium 3.7v 3800mAh Li-ion Battery

This lithium-ion battery with a protection circuit offers 14Wh power (3800mAh, 3.7V) with strong applicability and stable performance. It features long life, high energy density, wide temperature range, and stable discharge voltage. The battery comes with soldered wires, ready to be connected in your project.
36.75 AED 36.75 AED Tax Included
36.75 AED Tax Included

Not Available For Sale

This combination does not exist.

Terms and Conditions
30-day money-back guarantee
Shipping: 2-3 Business Days



Specifications

  • Battery Type: Lithium Ion Battery With Protection Circuit
  • Rated Voltage: 3.7V
  • Capacity: 3800mAh
  • Protection Circuit Module (PCM): Yes
  • Soldered Wires: Yes
  • Configuration: 1S1P
  • Watt-Hour Rating: 14Wh
  • Max Operating Voltage Range: 2.75V to 4.2V
  • Max Charge Voltage: 4.2V ± 50mV
  • Working Temperature: -20℃ ~ 60℃
  • Discharge Shutdown: 2.75V
  • Expected Life: 500 cycles ≥ 80% capacity at 23 ± 5℃

Notice

  1. To maintain capacity, store the battery at -0 ~ 35℃ with low humidity and non-corrosive gas.
  2. Avoid storing at high temperature or humidity to prevent leakage, rust, or low capacity.
  3. Long-term storage may reduce capacity; 1-3 charge/discharge cycles are needed to reach maximum discharge capacity.
  4. After three months of storage, charge and discharge the battery to avoid over-discharging.
  5. Instant over-discharge followed by immediate charging will not damage the battery, but long-term over-discharge can cause damage.
