Features
- Evaporation function
- Automatic trickle function
- Anti-reverse connection protection
- Over-voltage and overcharge protection
- Auto shutoff when fully charged
- Short circuit protection
- Short start function
- Wide voltage range
- LCD Display
- Three-phase charging (PWM mode): constant current, constant voltage, floating charge
Specifications
- Battery Type: Storage battery
- Applicable Battery: 12Ah - 100Ah
- Charger Current: 5-6A
- Input Voltage: 110V - 240V
- Output Voltage: 12V
- Rated Frequency: 47 - 63Hz
- Full Load Efficiency: ≥ 87%
- Working Temperature: -40°C ~ +95°C
Charging Modes
Constant Current Mode
When the battery voltage falls below the set value, the charger operates in constant current mode, supplying a stable current to the battery.
Constant Voltage Mode
Using PWM control, the charger regulates the charging current and output voltage, ensuring the battery is fully charged and protected from overcharging.
Floating Charge Mode
When the battery voltage approaches the constant voltage value, the current gradually decreases. At this stage, the battery is fully charged, the indicator lamp turns green, and the fan stops. The charger then switches to floating charge mode. The battery can be disconnected or left on a floating charge for up to half an hour.
