GSM Particle IoT 3G Electron Cellular Kit
Particle's Electron is a compact cellular IoT development kit designed for creating 3G cellular-connected products. It includes a prepaid data plan without a contract, enabling immediate internet connectivity and wireless programming. The kit also provides Particle's development tools and cloud platform for managing and updating connected hardware. It's compatible with GSM networks and supports GSM 900/1800 MHz frequencies for use in Europe, Africa, and Asia.
Package Includes
- Microcontroller
- Particle SIM card (service in 100+ countries)
- 3 months of 1MB monthly data plan (delivered via email)
- Antenna x 1
- 2000mAh battery x 1
- USB cable x 1
- Half-size breadboard x 1
Features
- Cellular Modules: U-blox SARA-U350
- Microcontroller: STM32F205RGT6 120MHz ARM Cortex M3
- Memory: 1MB flash, 128KB RAM
- Power Management: BQ24195 power management unit and battery charger, MAX17043 fuel gauge
- Other:
- RGB status LED
- 30 mixed-signal GPIO and advanced peripherals
- Open source design
- Real-time operating system (RTOS)
- Certified by FCC (United States), CE (European Union), and ISED (Canada)
Pinout
| Pin | Description |
|---|---|
| VIN | Can be used as input or output. As input, supply 5V–12VDC to power Electron. As output, ~4.8VDC (max load 1A). |
| RST | Active-low reset input with 10kΩ pull-up and 0.1µF capacitor. |
| VBAT | Supplies RTC, backup registers, and SRAM when 3V3 not present. Can be externally powered (requires internal resistor removal). |
| 3V3 | Outputs 3.3VDC (max 800mA). Not for input power use. |
| WKP | Active-high wakeup pin; also GPIO, ADC input, or PWM. |
| DAC | 12-bit Digital-to-Analog output (DAC1). Also GPIO or ADC. |
| RX / TX | UART RX/TX, also GPIO or PWM. |
| D0–D7 | Digital GPIO; D0–D3 can be PWM outputs. |
| A0–A7 | 12-bit ADC inputs and GPIO; A6 = DAC, A7 = WKP, A3 = second DAC. A4/A5 can be PWM. |
| B0–B5 | B0/B1 digital only; B2–B5 ADC + GPIO; B0–B3 PWM capable. |
| C0–C5 | Digital-only GPIO; C4/C5 support PWM. |
| VUSB | USB 5V supply. Outputs 5V when USB plugged in. |
| Li+ | Internally connected to LiPo battery positive terminal. |
