Powering the module is made easy with the 5V power supply or the option to use it for eMMC burning. It also features a user button and a USB 2.0 connector for connecting a variety of USB devices. In addition, it has a CSI connector for the MIPI CSI camera interface and a DSI connector for the MIPI DSI display interface. The CM4 Nano Base Board also has a mini HDMI connector that supports 4K 30fps output, making it ideal for high-resolution video applications.
The BOOT switch allows you to easily switch between a USB to Type-C interface, which will enter download mode when powered on (configured as a large-capacity disk through RPI boot), or a USB to Type A interface, which will not enter download mode when powered on (booted from eMMC or Micro SD card).
The Raspberry Pi 4 Computer Module CM4 Nano Base Board is an ideal choice for embedded systems, IoT projects, and other applications that require a compact, powerful, and versatile computing solution.
Specifications:
| CM4 SOCKET | Suitable for all variants of Compute Module 4 |
| NETWORKING | Gigabit Ethernet RJ45 connector |
| CONNECTOR | Raspberry Pi 40PIN GPIO header × 1 |
| USB | USB 2.0 Type A connector × 1 |
| DISPLAY | MIPI DSI port × 1 (15pin 1.0mm FPC connector) |
| CAMERA | MIPI CSI-2 port × 1 (15pin 1.0mm FPC connector) |
| VIDEO | Mini HDMI port × 1, supports 4K 30fps output |
| AUDIO | 3.5mm jack |
| STORAGE | Micro SD card socket for Compute Module 4 Lite (without eMMC) variants |
| POWER INPUT | 5V |
| DIMENSIONS | 56 × 41mm |
| WEIGHT | 0.019 kg |
Features:
- Compatible with all variants of the Compute Module 4 through the CM4 socket
- 40PIN GPIO header for connecting a variety of HATs
- Gigabit Ethernet RJ45 connector for high-speed networking
- Power supply options include 5V power supply or eMMC burning
- 3.5mm audio jack for audio input/output
- User button for additional functionality
- USB2.0 connector for connecting various USB devices
- MIPI CSI camera interface through the CSI connector
- MIPI DSI display interface through the DSI connector
- Mini HDMI connector supports 4K 30fps output
- BOOT switch to easily switch between USB to Type C and USB to Type A interfaces, allowing to enter download mode or not and boot from eMMC or Micro SD card
- MP1658 support
Pinout:
| CM4 socket | Suitable for all variants of Compute Module 4 |
| Micro SD card slot | For connecting a Micro SD card with pre-burnt image (Lite variant ONLY) |
| 40PIN GPIO header | For connecting sorts of HATs |
| Gigabit Ethernet RJ45 connector | For high-speed networking |
| Power supply / Programming | 5V power supply, or used for eMMC burning |
| 3.5mm audio jack | For audio input/output |
| User button | |
| USB2.0 connector | For connecting sorts of USB devices |
| CSI connector | MIPI CSI camera interface |
| DSI connector | MIPI DSI display interface |
| MP1658 | |
| Mini HDMI connector | Supports 4K 30fps output |
| BOOT switch | ON: USB to Type C, enters download mode when powered on. OFF: USB to Type A, does not enter download mode, boots from eMMC or Micro SD card |
