DC-DC Buck Converter 60W Adjustable Module (DFRobot) - DFR1025
Still bothered by how to correctly power your RGB LED strip or achieve smooth servo movement? Don’t worry, this 60W DC-DC buck converter takes care of everything. This buck converter module converts high-power 12V or lithium battery 11.1V to 5V output. 60W power can be available with just one module.
Package Includes:
- 60W Adjustable DC-DC Buck Converter x1
- 2Pin Terminal Block x2
- Aluminum Heat Sink x1
Featuring adjustable 0.6V-5.1V output voltage and up to 18A output current, the module can drive a 5m WS2812 RGB strip or any device requiring low voltage and high current. Additionally, the converter incorporates protective functions like short-circuit protection, over-current protection, and overheating protection to ensure stable performance.
FEATURES
- Industrial-grade module, ensures long-term stable operation
- 1.8~5.1V output voltage adjustable
- High output current
SPECIFICATION
- Input Voltage: 9V-15V
- Output Voltage: 0.6V-5.1V
- Output Current: 18A (Active Dissipation)
- Output Power: 60W (Active Dissipation)
- Conversion Efficiency: 92% (Typical)
- Outline Dimension: 52×37mm / 2.05×1.46”
Safe Operating Range
The parameters of the safe operating range are tested in typical experimental environments. It is recommended to measure the surface temperature of the buck converter to determine if heat dissipation needs to be improved.
- Surface temperature < 80℃: the converter performs steadily
- Surface temperature 80 - 90℃: dissipation improvement recommended
- Surface temperature > 90℃: dissipation improvement required, as the overheat protection may be triggered at any time
APPLICATIONS
- Industrial applications
- Battery-powered devices
- LED lighting
- Communication equipment
