Features:
- CAN Frame Support: Supports both CAN2.0A (standard) and CAN2.0B (extended) frames.
- Configurable Baud Rate: Adjustable from 5Kbps to 1Mbps to suit different network speeds.
- Versatile Operating Modes: Includes normal, loopback, silent, and silent loopback modes for diverse testing scenarios.
- Flexible Data Sending: Supports single frame, multiple frames, manual, regular, and cyclic sending modes.
- Selective Data Reception: Receive data from specific IDs or automatically respond to configured data.
- Data Logging: Save received data in TXT or Excel format for analysis.
- CAN Bus Detection: Easily check the status of the CAN network.
- Time-Scale Data Handling: Send and receive CAN data sequentially for debugging.
- USB Virtual COM Port: Baud rate configurable from 9600 to 2,000,000bps for host compatibility.
- Configuration Options: Parameters can be set via software or serial commands and saved after power-off.
- STM32 Chip: Reliable and stable communication solution.
- ESD Protection: Onboard TVS suppress surge and transient voltages for circuit safety.
- Windows Software: User-friendly master computer software compatible with Windows.
- Secondary Development: Modify sending/receiving commands for custom applications.
Primary Function:
Using in Windows System:
- USB Driver Installation: Download
CH341SER.zip, runCH341SER.EXE, and follow instructions to install the driver.
