IC Logic Gate 74LS11 3-Input AND
The 74LS11 IC is a versatile component offering three independent positive logic 3-input AND Gates. Designed to meet a range of working conditions, this IC stands out for its compatibility with CMOS, NMOS, and TTL, delivering TTL outputs for seamless integration with other TTL devices and microcontrollers.
Package Includes
- 74LS11 IC x1
Features
- Three Independent AND Gates: The IC package houses three positive logic 3-input AND Gates, providing flexibility for various applications.
- Wide Working Voltage Range: Operates within a broad voltage range, enhancing adaptability to different working conditions.
- Interfacing Compatibility: Directly interfaces with CMOS, NMOS, and TTL, ensuring seamless integration into diverse electronic systems.
- TTL Output: Outputs are consistently in TTL, simplifying compatibility with other TTL devices and microcontrollers.
- Compact Size and High Speed: Smaller size and high-speed performance contribute to reliability across a spectrum of devices.
Specifications
- Logic type: AND/Direct Logic
- Operating voltage: 4.75 V to 5.25 V
- Current: 8 mA
- Working temperature: 0 °C to 75 °C
- No. of Inputs: 3
- No. of Outputs: 1
- Gates: 3
- Pins: 14
- Low Power Consumption: Optimized for energy efficiency
- Rise Time: 18 ns (Typical)
- Fall Time: 18 ns (Typical)
Pin Configuration
- A1 - INPUT 1 of GATE 1
- B1 - INPUT 2 of GATE 1
- A2 - INPUT 1 of GATE 2
- B2 - INPUT 2 of GATE 2
- C2 - INPUT 3 of GATE 2
- Y2 - OUTPUT of GATE 2
- GND - Ground
- Y3 - OUTPUT of GATE 3
- A3 - INPUT 1 of GATE 3
- B3 - INPUT 2 of GATE 3
- C3 - INPUT 3 of GATE 3
- Y1 - OUTPUT of GATE 1
- C1 - INPUT 3 of GATE 1
- VCC - Supply Voltage
Applications
- Provides essential TTL outputs required in specific systems.
- Ideal for scenarios demanding 3-input logical AND operations.
- Commonly used in devices such as personal computers and notebooks.
