Connector DB9 Male For RS232/RS422/RS485 (DFRobot) - FIT0108
This is a quality DB9 Male Connector with solder tail package. DB9 connector is widely used for serial communication RS232, RS485, and RS422 interfaces.
Package Includes:
- DB9 Male Connector x1
RS-232 Maximum Cable Length
The maximum cable length for RS-232 is 50ft, but in practice, it depends on baud rate, cable specific capacitance, and ambient noise. The table below contains some rules-of-thumb from experiments done by Texas Instruments years ago.
| Baud rate | Maximum range / cable length |
|---|---|
| 19200 | 50 ft |
| 9600 | 500 ft |
| 4800 | 1000 ft |
RS232 DB9 Pinout Diagram
RS-232 Maximum Cable Length
The maximum cable length for RS-232 is 50ft, but in practice, it depends on baud rate, cable specific capacitance, and ambient noise. The table below contains some rules-of-thumb from experiments done by Texas Instruments years ago.
| Baud rate | Maximum range / cable length |
|---|---|
| 19200 | 50 ft |
| 9600 | 500 ft |
| 4800 | 1000 ft |
RS232 DB9 Pinout Diagram
