LCD 1024x600 10.1 DVI IPS Panel Display Module For Raspberry PI Pico
This high-resolution display module is specifically designed for use with the Raspberry Pi Pico. Featuring an IPS panel and DVI interface, it offers fast communication and superior visual performance. The onboard 40-pin header ensures seamless connectivity, and the integrated OSD menu allows brightness and contrast adjustments. This display is ideal for advertisement displays and other large-format visual applications. Development resources are available in C/C++ for Raspberry Pi Pico.
Package Includes
- 1 x 10.1 inch DVI Display Module
- Note: Raspberry PI Pico is not included
Features
- IPS Panel with 1024×600 Resolution: Offers vibrant colors and a wide 170° viewing angle. Max resolution may be limited to 400×240 pixels when using RGB565 color format due to RP2040 memory constraints.
- DVI Interface: Ensures high-speed data transfer with Raspberry Pi Pico.
- Onboard 40-Pin Header: Simplifies connectivity with the Raspberry Pi Pico.
- On-Screen Display (OSD) Menu: Allows user adjustment of brightness and contrast.
- Available in Multiple Sizes: Comes in 7-inch and 10.1-inch versions for different applications.
- Versatile Applications: Suitable for advertisement picture displays and similar use cases.
- Comprehensive Online Resources: Includes C/C++ examples, documentation, and development tools.
Specifications
- Operating Voltage: 5V
- Resolution: 1024 x 600 pixels
- Communication Interface: DVI
- Display Panel Type: IPS
- Display Size: 222.72 × 125.28 mm
- Pixel Size: 0.2175 × 0.2088 mm
Pinout
The pinout diagram below illustrates the connection points between the Raspberry Pi Pico and the display module, including power, ground, and DVI signal lines.
Documentation
- Schematic: PICO-DVI-LCD Schematic
- Example Demo: RP2040-DVI-LCD-Code.zip
- Thonny Python IDE (Windows V3.3.3): Download Thonny
- Zimo221 Software: Download Zimo221.7z
- Image to LCD Converter: Download Image2Lcd.7z
- WIKI: Waveshare PICO-DVI-LCD Wiki
- MicroPython Demo: MicroPython Demo on GitHub
- Firmware/Blink Demo: MicroPython Firmware/Blink Demo (C)
- Official Raspberry Pi C/C++ Demo: C/C++ Examples
- Official Raspberry Pi MicroPython Demo: MicroPython Examples
- Arduino C/C++ Demo: Arduino Demo
