Features

• RP2350 microcontroller chip officially designed by Raspberry Pi
• Adopts unique dual-core and dual-architecture design, equipped with dual-core ARM Cortex-M33 processor and dual-core Hazard3 RISC-V core processor, flexible clock running up to 150 MHz
• Built-in 520KB of SRAM and 2MB of on-chip Flash
• Onboard 1 USB port, compatible with USB2.0/1.1 transmission
• Castellated module allows soldering directly to carrier boards
• Drag-and-drop programming using mass storage over USB
• 15 × multi-function GPIO pins of RP2350
• Multiple hardware peripherals
  • SPI × 2
  • I2C × 2
  • UART × 2
  • 12-bit ADC × 4
  • Controllable PWM channel × 14
• Built-in temperature sensor on chip
• 12 × Programmable I/O (PIO) state machines for custom peripheral support

Pinout Definition

Dimensions

Resources

Supporting Resources

Document

• RP2350-USB-A Schematic diagram

Demo

• RP2350-USB-A Demo

Official Resources

Raspberry Pi Official Documents

• Get Started with MicroPython on Raspberry Pi Pico
• Raspberry Pi related books download
• Pico2 Schematic diagram
• Pico2 Pinout definition
• Pico2 Getting Started
• Pico2 C SDK User Manual
• Pico2 Python SDK User Manual
• Pico2 Datasheet
• RP2350 Datasheet
• RP2350 Hardware Design Reference Manual
